Lesson 5 – Synthesis of a Band Pass Filter

Step 1 1 Open a new project with File > New > Single Fiber. 2 Calculation > Inverse Scattering Solver, to get Inverse Problem Solver dialog box. 3 Select User Defined frame checkbox. 4 Enter the starting and ending wavelengths, and the number of steps in the User-Defined frame as shown. The Steps field indicates the number…
