Lesson 7 – Four Wave Mixing
Four Wave Mixing Introduction
OptiFDTD provides two dimension nonlinearity and multiple input wave simulations, thereby enabling you to simulate the Four Wave Mixing (FWM) effect. The following lesson outlines how OptiFDTD performs a FWM simulation. To create the Four Wave Mixing layout, perform the following procedures. Designing a four-wave mixing layout To design the four-wave mixing materials, perform the following…
Spectral Analysis in Observation Point
When the simulation ends, a message appears and prompts you to open OptiFDTD_Analyzer (see Figure 23). Figure 23: Message box Step Action 1 To open OptiFDTD_Analyzer and view the simulated results, click Yes. Note: When the simulation ends, the results are saved automatically as a file with same name but a different file extension (*.fda). 2 Select Tools > Observation Area Analysis. The Observation Area Analysis dialog…
